| Dimensions |
976 x 335 x 231mm (HWD) |
| Working Temperature |
-30 C~+70 C |
| Power Supply |
DC 24V |
| Open/close Speed |
0.8 Within 3mtr, 1.5s Within 4.5mtr, 2 to 6s Within 6mtr |
| Motor Power |
160W |
| Driving Method |
DC Brushless |
| Torque |
56.8N.m |
| Remote Control Distance |
≤100m (Open environments) |
| Protection Grade |
IP54 |
| Input Interface |
Radar and Ground Loop detector, photo cell |
| Motor No - load Speed |
1850r/min |
| MCBF |
10 M+ |
| Max Boom Length |
Upto 6m |
| LED indicator |
Yes, Red/Green |
| Power failure Action |
Auto Open |
| Arm swing-out function |
Yes, When the vehicle hit the barrier gate, the arm can be swing out to avoid further damage |
| Boom Type |
Straight Arm |
