Flap Barrier (NS-FS1-V31D1/2)

About this product

  • The flap barrier is a completely automated system, operated by a 24V brushless DC motor. It offers versatile opening modes such as ID and IC card swiping.
  • The mechanical components are crafted using CNC processes, guaranteeing long-term durability without deformation.
  • The implementation of a guide rail movement structure ensures a stable and smooth operation.
  • The flap barrier also features an automatic reset function for added convenience.
  • An infrared alarm is integrated to detect and alert for any unauthorized intrusion.
  • It is equipped with audible and visual alarm functions to detect illegal intrusion, trailing, and gate closure.

Appearance Dimension 1200*300*1000mm
Material Structure 304 original brushed stainless steel, acrylic
Channel Width 550mm
Drive Motor 24V DC brushless motor, low noise
Thickness The full thickness of the outer box is 1.2 + 1.0mm
Traffic Speed Traffic Speed
Traffic Direction One-way traffic/two-way traffic
Movement Structure Guide rail structure
Opening Mode ID / IC card swiping and other reading head verification opening, infrared induction automatic opening, button opening, etc.
Opening Signal Dry contact signal
Protection Function Current anti pinch, infrared anti pinch, illegal intrusion infrared alarm
Service Life ≥ 6 million times
Infrared Quantity 3 pairs (4 pairs can be customized)
Power 30-60w
Applicable Temperature -15~75 ℃ (add thermostat below this temperature)
Optional Accessories
